Запчасти Komatsu PC180LC-7-E0 ЦИЛИНДР РУКОЯТИДЛЯ 2 ЧАСТИ СТРЕЛА (STD) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

707-01-XN630

CYLINDER GROUP

|1

707-01-XL480

CYLINDER ASS'Y

1

707-13-12650

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-85310

ROD,PISTON

5

707-27-12650

HEAD,CYLINDER

6

07179-13099

RING,SNAP

7

707-56-85510

SEAL,DUST (KIT)

8

707-52-90610

BUSHING

9

707-75-85110

RING,SNAP

10

707-51-85030

PACKING,ROD (KIT)

11

07000-15110

O-RING (KIT)

12

707-35-91220

RING,BACK-UP (KIT)

13

707-51-85650

RING,BUFFER (KIT)

14

01010-81670

BOLT

15

01643-51645

WASHER

16

707-36-12851

PISTON

17

707-44-12150

RING,PISTON (KIT)

18

707-39-12140

RING,WEAR (KIT)

19

707-44-12911

RING

20

707-71-70820

PLUNGER

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

707-71-80230

PLUNGER

25

07020-00000

FITTING,GREASE

26

707-71-32590

COLLAR

27

707-35-91220

RING,BACK-UP (KIT)

28

07000-15110

O-RING (KIT)

29

04260-00635

BALL

30

707-71-91270

CAP

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

35

21K-62-K2010

BRACKET

36

21K-62-K1420

BRACKET

37

707-88-21620

BAND

38

707-88-21630

BAND

39

21K-62-K1370

TUBE

40

02782-10628

ELBOW

41

07002-12434

O-RING

42

02896-11018

O-RING

43

21K-62-K1970

TUBE

44

07000-13030

O-RING

45

07375-21045

BOLT SEM

46

07375-21060

BOLT SEM

47

07283-32738

CLIP

48

01597-01009

NUT

49

01643-31032

WASHER

50

20Y-62-13650

CLAMP

51

20Y-62-13450

PLATE

52

01010-81230

BOLT

53

07049-01215

PLUG

54

07375-21035

BOLT SEM

|K

707-98-48610

SERVICE KIT
