Запчасти Komatsu PC180LC-7-E0 ЦИЛИНДР СТРЕЛЫ(С РУКОЯТЬ CRANE) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XN610

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XN620

CYLINDER GROUP,R.H. (FINAL COATING)

|1

707-01-0L100

CYLINDER ASS'Y

1

707-13-11790

CYLINDER

2

707-58-75650

ROD,PISTON

3

21K-70-71320

BUSHING

4

07145-00070

SEAL,DUST (KIT)

5

07020-00000

FITTING,GREASE

6

21K-70-71320

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

707-71-32580

COLLAR

9

07000-15100

O-RING (KIT)

10

707-71-70810

PLUNGER

11

707-35-91130

RING,BACK-UP (KIT)

12

707-27-11650

HEAD,CYLINDER

13

144-63-94170

SEAL,DUST (KIT)

14

07179-13089

RING,SNAP

15

707-51-75030

PACKING,ROD (KIT)

16

707-51-75650

RING,BUFFER (KIT)

17

07000-15100

O-RING (KIT)

18

707-35-91130

RING,BACK-UP (KIT)

19

707-52-90500

BUSHING

20

707-75-75110

RING,SNAP

21

01010-81670

BOLT

22

01643-51645

WASHER

23

721-36-11020

PISTON

24

707-44-11150

RING,PISTON (KIT)

25

707-39-11150

RING,WEAR (KIT)

26

707-44-11911

RING

27

01310-01216

SCREW

28

07000-15070

O-RING (KIT)

29

707-35-90360

RING,BACK-UP (KIT)

30

707-86-68270

TUBE,L.H.

|30

707-86-68280

TUBE,R.H.

31

02896-61015

O-RING (KIT)

32

01010-80840

BOLT

33

01643-50823

WASHER

34

07000-13025

O-RING (KIT)

35

707-88-22950

BRACKET,L.H.

|35

707-88-22960

BRACKET,R.H.

36

707-88-21640

BAND

37

07372-21035

BOLT

38

01643-51032

WASHER

39

07283-32236

CLIP

40

01597-01009

NUT

41

01643-31032

WASHER

42

01010-80845

BOLT

43

01643-50823

WASHER

44

02789-00522

NUT

45

07371-30640

FLANGE

46

707-88-33030

HEAD

47

07372-21035

BOLT

48

01643-51032

WASHER

|K

707-99-38760

SERVICE KIT
