Запчасти Komatsu PC180LC-6K ЦИЛИНДР КОВША(№K-K) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K3700

CYLINDER ASS'Y,BUCKET

|1

21P-63-K3600

CYLINDER ASS'Y

1

21P-63-K3270

SHELL ASS'Y

2

21P-63-K3290

ROD ASS'Y,PISTON

3

707-27-10670

HEAD,CYLINDER

4

707-36-10510

PISTON

5

07165-15252

NUT

6

01010-81465

BOLT

7

705-17-04980

WASHER

8

144-63-95170

SEAL,DUST

9

07176-12084

RING,SNAP

10

707-51-70030

PACKING,ROD

11

707-51-70630

RING,BUFFER

12

07000-15100

O-RING

13

07001-05100

RING,BACK-UP

14

707-52-90450

BUSHING

15

707-44-10911

RING,PISTON

16

707-39-10520

RING,WEAR

17

707-44-10280

RING

18

707-76-70230

BUSHING

19

07145-00070

SEAL,DUST

20

707-76-70370

BUSHING

21

21K-70-12180

SEAL,DUST

22

07020-00000

FITTING,GREASE

23

07020-00900

FITTING,GREASE

24

21P-63-K2140

TUBE

25

707-88-96181

BAND

26

21P-63-K3330

BRACKET

27

07282-02288

CLAMP

28

01010-81020

BOLT

29

01643-31032

WASHER

30

01010-81035

BOLT

31

01643-31032

WASHER

32

01010-80850

BOLT

33

707-87-12830

ELBOW

34

07000-13025

O-RING

35

01643-50823

WASHER

36

07000-13030

O-RING

37

01010-81080

BOLT

38

01643-51032

WASHER
