Запчасти Komatsu PC180LC-6K ЦИЛИНДР РУКОЯТИ(№K-K) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K1801

CYLINDER ASS'Y,ARM

|1

21P-63-K1711

CYLINDER ASS'Y

1

21K-63-64140

CYLINDER

2

21K-63-64120

ROD,PISTON

3

707-27-12620

HEAD,CYLINDER

4

707-36-12411

PISTON

5

707-71-60901

PLUNGER

6

07165-15860

NUT

7

707-71-60200

PLUNGER

8

707-71-91270

CAP

9

04260-00635

BALL,STEEL

10

707-71-32620

COLLAR

11

01010-81670

BOLT

12

01643-51645

WASHER

13

707-56-85510

SEAL,DUST

14

07179-13099

RING,SNAP

15

707-51-85030

PACKING

16

707-51-85630

RING,BUFFER

17

07000-15115

O-RING

18

07001-05115

RING,BACK-UP

19

707-52-90600

BUSHING

20

707-44-12180

RING,PISTON

21

707-39-12110

RING,WEAR

22

707-44-12911

RING

23

707-76-80230

BUSHING

24

07145-00080

SEAL,DUST

25

07020-00675

FITTING,GREASE

26

21K-63-64170

TUBE

27

707-88-95861

BRACKET

28

707-88-99240

BAND

29

707-88-99250

BAND

30

707-88-95871

BRACKET

31

07283-22738

CLIP

32

07372-21045

BOLT

33

01643-51032

WASHER

34

01010-51035

BOLT

35

01643-31032

WASHER

36

07372-21060

BOLT

37

01599-01011

NUT

38

07000-13030

O-RING
