Артикул
Название
Примечание
Количество
G1
21P-63-K3500
CYLINDER ASS'Y
|1
20G-63-K1410
CYLINDER ASS'Y
1
20G-63-K1460
HEAD
2
20G-63-K1470
PISTON
3
20G-63-K1450
ROD ASS'Y
4
707-76-80230
BUSHING
5
07145-00080
SEAL
6
20G-63-K1420
SHELL ASS'Y
7
07145-00070
SEAL
8
707-76-70330
BUSHING
9
20G-63-K1480
SCREW
10
20G-63-K1490
PLUG
11
707-52-90600
BUSHING
12
707-51-85630
RING
13
707-56-85510
SEAL
14
707-51-85030
PACKING
15
07000-15115
O-RING
16
07001-05115
RING
17
707-44-12911
RING
18
707-44-12180
RING
19
707-39-12110
RING
20
07179-13099
RING
21
07020-00675
FITTING
22
01010-81670
BOLT
23
01643-51645
WASHER
24
707-71-60901
PLUNGER
25
20G-63-K1530
COLLAR
26
20G-62-K7040
TUBE
27
07000-13025
O-RING
28
01010-80850
BOLT
29
01643-50823
WASHER
30
20G-63-K7020
TUBE
31
07372-21035
BOLT
32
01643-51032
WASHER
33
07000-13030
O-RING
34
20G-62-K8020
BRACKET
35
707-88-99210
BAND
36
01010-81030
BOLT
37
01643-51032
WASHER
38
01010-81030
BOLT
39
01643-51032
WASHER
40
702-21-08021
PILOT VALVE ASS'Y,(SEE FIG.Y1665-01A0)
41
07372-21055
BOLT
42
01643-51032
WASHER
43
07372-21060
BOLT
44
01643-51032
WASHER
45
07000-13030
O-RING
46
07235-10210
ELBOW
47
07002-11423
O-RING
48
07235-10315
ELBOW
49
07002-12034
O-RING
Выбрано товаров: 51
