Запчасти Komatsu PC1800-6 ОСНОВН. КЛАПАН (4-Х СЕКЦИОНН.) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

709-14-93802

CONTROL VALVE

|$4

709-14-93801

CONTROL VALVE

|$5

709-14-93800

CONTROL VALVE

|$10

709-14-00112

BODY GROUP ASS'Y

|$11

709-14-00111

BODY GROUP ASS'Y

|$12

709-14-00110

BODY GROUP ASS'Y

1

BODY,VALVE

2

SPOOL

3

SPOOL SUB ASS'Y

3

SPOOL SUB ASS'Y

3

SPOOL SUB ASS'Y

4

SPOOL SUB ASS'Y

5

SPOOL SUB ASS'Y

6

700-22-11370

PLUG

7

07002-12434

O-RING

8

709-14-11510

PLUG

9

700-80-61260

O-RING

10

700-80-61430

RING

11

700-94-11260

PLUG

12

07002-13634

O-RING

13

07000-12018

O-RING

14

07001-02018

RING,BACK-UP

15

709-14-11520

CASE

15

709-14-11520

CASE

16

709-14-11530

RETAINER

16

709-14-11530

RETAINER

17

709-14-11550

SPRING

18

709-14-11560

SPRING

19

07000-12065

O-RING

19

07000-12065

O-RING

20

01252-61035

BOLT

21

709-12-11411

VALVE,CHECK

22

709-14-11581

VALVE,CHECK

23

709-12-11430

SPRING

24

709-14-11590

SPRING

25

709-14-11610

SEAT

26

709-14-12380

RETAINER

27

709-14-12390

CASE

28

6354-81-5670

O-RING
