Запчасти Komatsu PC1800-6 КОВШ (.M) (ГОРИЗОНТАЛЬН. ПАЛЕЦ) (HENSLEY) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

21T-920-0130

BUCKET ASS'Y

1

21T-920-6311

BUCKET

2

21T-70-34B91

PLATE (WELDED)

3

21T-70-34D11

PLATE (WELDED)

4

21T-70-34F10

PLATE (WELDED)

5

21T-70-34F20

PLATE (WELDED)

6

21T-70-34F40

PLATE (WELDED)

7

21T-70-34F50

PLATE (WELDED)

8

21T-70-34F60

PLATE (WELDED)

9

21T-70-34F70

PLATE (WELDED)

10

21T-70-34F80

PLATE (WELDED)

11

21T-70-34F90

PLATE (WELDED)

12

21T-70-34G10

PLATE (WELDED)

13

21T-70-34G40

PLATE (WELDED)

14

21T-70-34G50

PLATE (WELDED)

15

21T-70-34G60

PLATE (WELDED)

16

21T-70-34G70

PLATE (WELDED)

17

21T-70-64330

SHROUD (WELDED)

18

21T-70-34120

PLATE (WELDED)

19

21T-920-6340

PLATE (WELDED)

20

21T-920-6330

PLATE (WELDED)

21

21T-70-74280

BUSHING

22

21T-70-34150

ADAPTER (WELDED)

23

21T-70-34210

SHROUD

24

21T-70-34160

ADAPTER (WELDED)

25

21T-70-34210

SHROUD

26

21T-70-34170

ADAPTER (WELDED)

27

21T-70-34451

CAP

28

21T-70-34190

TOOTH

29

21T-70-34460

PIN ASS'Y

30

21T-70-74251

COVER

31

01011-83615

BOLT

32

01643-33690

WASHER

33

21N-70-14220

BUSHING

34

21T-70-00050

SHIM ASS'Y

34

SHIM, 1.0MM

34

SHIM, 0.5MM

35

21T-70-34220

GUARD

36

21T-70-34230

PIN

37

21T-70-34240

WASHER

38

21T-70-74290

COVER

39

21T-70-74310

COLLAR

40

01010-83070

BOLT
