/ / / / / / КРЕПЛЕНИЕ ДВИГАТЕЛЯ(№-999)
Запчасти Komatsu PC1800-6 КРЕПЛЕНИЕ ДВИГАТЕЛЯ(№-999) КОМПОНЕНТЫ ДВИГАТЕЛЯ
1
2
3
4
5
6
6
7
7
7
7
7
8
8
9
10
10
11
11
12
13
13
14
14
15
16
17
18
19
20
21
22
23
23
23A
23B
23C
23D
23E
24
24
24
1
21T-01-71111
BRACKET,L.H.
2
21T-01-71170
BRACKET,R.H.
3
01010-82070
BOLT
4
15R-70-16370
WASHER
5
04020-01842
PIN
6
21T-01-11210
COLLAR
7
21T-01-11150
CUSHION
8
21T-01-11220
COLLAR
9
209-01-51133
STOPPER
10
209-01-51142
STOPPER
11
21T-01-11180
WASHER
12
21T-01-11190
WASHER
13
208-01-11181
BOLT
14
01643-32460
WASHER
15
21T-01-11230
PLATE
16
21T-01-11210
COLLAR
17
21T-01-11150
CUSHION
18
21T-01-11220
COLLAR
19
209-01-51133
STOPPER
20
209-01-51190
STOPPER
20
209-01-51142
STOPPER
21
208-01-11181
BOLT
22
01643-32460
WASHER
23
21T-01-67330
PLATE
23A
209-01-51210
SPACER
23B
209-01-51220
PLATE
23C
01010-81235
BOLT
23D
01643-31232
WASHER
23E
209-01-00020
SHIM ASS'Y
23E
SHIM, 1.0MM
23E
SHIM, 0.5MM
24
21T-01-00010
SHIM ASS'Y
24
SHIM, 0.1MM
24
SHIM, 0.3MM
24
SHIM, 0.5MM
24
SHIM, 1.0MM
