Запчасти Komatsu PC1800-6 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ680

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

21T-63-X2350

CYLINDER GROUP,L.H.

G-2

707-01-XZ690

CYLINDER GROUP,R.H. (FINAL COATING)

G-2

21T-63-X2360

CYLINDER GROUP,R.H.

|$6

21T-63-02350

CYLINDER ASS'Y

1

21T-63-72740

CYLINDER

2

21T-63-72720

ROD,PISTON

3

707-46-14010

BUSHING

4

21T-72-15850

BUSHING

5

21T-72-15860

BUSHING

6

21T-72-15870

SEAL (KIT)

7

07179-14160

RING,SNAP

8

198-63-93170

SEAL,DUST (KIT)

9

707-27-20630

HEAD,CYLINDER

10

707-51-14080

PACKING,ROD (KIT)

11

07001-05195

RING,BACK-UP (KIT)

12

07000-15195

O-RING (KIT)

13

707-51-14630

RING,BUFFER (KIT)

14

707-52-91150

BUSHING

15

01011-82705

BOLT

16

01643-32780

WASHER

17

707-71-31470

COLLAR

18

707-71-31580

COLLAR

19

707-71-11450

RING

20

707-71-51490

PLUNGER

21

07000-12115

O-RING (KIT)

22

707-35-52860

RING,BACK-UP (KIT)

23

707-36-20300

PISTON

24

707-36-20240

PISTON

25

707-44-20180

RING,PISTON (KIT)

26

707-39-20820

RING,WEAR (KIT)

27

707-44-20910

RING

28

707-40-20860

SPACER

29

01253-61400

BOLT

30

07043-00108

PLUG

31

21T-63-72770

TUBE,L.H.

31

21T-63-72870

TUBE,R.H.

32

21T-62-88230

TUBE,L.H.

32

21T-62-88250

TUBE,R.H.

33

707-88-87361

BRACKET

33

707-88-87360

BRACKET

34

707-88-87370

BRACKET

35

707-88-96110

BAND

36

01010-81240

BOLT

37

01643-31232

WASHER

38

07000-13038

O-RING (KIT)

39

01010-81280

BOLT

40

01643-31232

WASHER

41

07000-13048

O-RING (KIT)

42

01010-81450

BOLT

43

01643-31445

WASHER

44

176-61-41330

CLAMP

45

01010-81250

BOLT

46

01643-31232

WASHER

47

707-88-88480

PLATE

48

01010-81225

BOLT

49

01643-31232

WASHER

50

07283-24346

CLIP

51

01599-01011

NUT

52

01643-31032

WASHER

53

07000-13048

O-RING,(FOR SHIPPING)

54

07378-11410

HEAD,(FOR SHIPPING)

55

07371-51470

FLANGE,(FOR SHIPPING)

56

01010-81455

BOLT,(FOR SHIPPING)

57

01643-31445

WASHER,(FOR SHIPPING)

|$68

707-99-77130

SERVICE KIT
