/ / / / / / ОХЛАЖД-Е (ВТОРИЧН. БАК)(№-)
Запчасти Komatsu PC1800-6 ОХЛАЖД-Е (ВТОРИЧН. БАК)(№-) СИСТЕМА ОХЛАЖДЕНИЯ
1
1
1
1
1A
1A
1B
1B
1C
1C
2
2
3
3
4
4
4
4
5
6
7
8
9
9
10
10
11
11
12
12
13
13
14
14
15
16
17
18
18
18
19
19
20
20
21
22
23
23
23
23
24
25
26
27
27
27
27
28
28
29
30
31
31
32
32
33
33A
34
34
35
35
36
37
38
39
39
40
40
41
41
42
42
43
43
44
44
45
45
45
45
46
46
47
47
47
47
48
48
49
49
50
50
51
52
52
53
54
1
21N-03-31490
TANK
1A
21N-03-32360
CAP ASS'Y
1B
21N-03-32350
CAP ASS'Y
|$5
ND071370-0190
SWITCH
1C
08055-00282
CONNECTOR
2
208-03-58310
HOSE, 600MM
3
209-03-77440
HOSE, 300MM
4
07285-00110
CLIP
5
21T-03-64181
BRACKET
6
205-03-71440
SHEET,SEMS
7
01010-81220
BOLT
8
01643-31232
WASHER
9
21T-03-67252
BAND
10
01010-80820
BOLT
11
01643-30823
WASHER
12
209-03-71291
HOSE
13
209-03-77370
HOSE, 3700MM
14
07285-00110
CLIP
15
04435-51212
CLIP
16
01010-81220
BOLT
17
01643-31232
WASHER
18
04434-51212
CLIP
19
01010-81220
BOLT
20
01643-31232
WASHER
21
209-03-77430
HOSE, 450MM
22
209-03-77440
HOSE, 300MM
23
07285-00110
CLIP
24
04435-51212
CLIP
25
01010-81220
BOLT
26
01643-31232
WASHER
27
209-03-77370
HOSE, 3700MM
28
07285-00110
CLIP
29
04434-51212
CLIP
30
04435-51212
CLIP
31
01010-81220
BOLT
32
01643-31232
WASHER
33
21T-03-64310
BRACKET
33A
205-03-71440
SHEET
34
01010-81230
BOLT
35
01643-31232
WASHER
36
21T-03-64320
BRACKET
37
01010-81230
BOLT
38
01643-31232
WASHER
39
21N-03-32210
JOINT
40
04434-50812
CLIP
41
01010-81220
BOLT
42
01643-31232
WASHER
43
209-03-71291
HOSE
44
209-03-77370
HOSE, 3700MM
45
07285-00110
CLIP
46
04434-51312
CLIP
47
04435-51312
CLIP
48
01010-81220
BOLT
49
01643-31232
WASHER
50
08037-03620
GROMMET
51
209-03-78170
SHEET
52
04434-51012
CLIP
53
01010-81220
BOLT
54
01643-31232
WASHER
