Запчасти Komatsu PC1800-6 ОХЛАЖД-Е (РАДИАТОР)(№-) СИСТЕМА ОХЛАЖДЕНИЯ
1
2
3
3
4
5
5
6
6
6
6
7
7
7
7
8
8
9
9
10
10
11
11
12
12
12
12
13
13
14
14
15
16
17
17
18
18
19
19
19
19
20
20
21
21
22
23
24
24
25
26
27
28
29
29
29
29
30
30
31
31
32
33
33
34
35
35
36
36
37
38
39
40
41
42
42
43
44
45
|$2
209-03-77100
RADIATOR ASS'Y
1
209-03-77330
TANK
2
209-03-71170
CAP
3
209-03-71110
CORE
4
209-03-71131
TANK
5
209-03-71220
PLATE
6
209-03-71231
PLATE
7
209-03-71240
PLATE
8
209-03-71790
PLATE
9
209-03-71260
GASKET
10
01010-81030
BOLT
11
01602-21030
WASHER
12
209-03-71161
BRACKET
13
01010-81235
BOLT
14
01602-21236
WASHER
15
209-03-71141
SUPPORT
16
209-03-71151
SUPPORT
17
01010-81235
BOLT
18
01643-31232
WASHER
19
209-03-71270
SHEET
20
209-03-71280
SHEET
21
21T-03-67460
OIL COOLER
22
01010-81225
BOLT
23
01643-31232
WASHER
24
6212-62-4100
AFTERCOOLER ASS'Y
25
01010-81240
BOLT
26
01643-31232
WASHER
27
21T-03-64211
SHROUD
28
201-43-28440
GROMMET
29
209-03-71350
SHEET
30
209-03-71360
SHEET
31
209-03-71370
SHEET
32
21T-03-64260
SHEET
33
21T-03-64270
SHEET
34
21T-03-67180
SHEET
35
21T-03-67190
SHEET
36
21T-03-67210
SHEET
37
21T-03-67220
SHEET
38
01010-81635
BOLT
39
21T-09-11330
WASHER
40
01010-81655
BOLT
41
01010-81650
BOLT
42
21T-09-11330
WASHER
43
07283-31079
CLIP
44
01599-01214
NUT
45
01643-31232
WASHER
