Запчасти Komatsu PC1800-6 ОСНОВН. НАСОС (8/) (ПОВОРОТН. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-1H-00320

PUMP ASS'Y

|$3

708-17-07140

SERVO VALVE ASS'Y,FRONT

|$4

708-17-07540

VALVE ASS'Y,CO + NC

|$5

708-23-00430

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-17460

PLUG

4

708-25-17430

SCREW

5

07000-B2010

O-RING

6

708-25-17131

COVER

7

01580-10806

NUT

8

708-25-17141

SPOOL

9

708-25-17150

SLEEVE

10

708-25-17160

PISTON

11

708-25-17170

COVER

12

07000-B2014

O-RING

13

708-25-17180

SEAT

14

708-25-17690

SPRING

15

708-25-17451

SLEEVE

16

708-25-17220

PISTON

17

708-25-17370

SEAT

18

708-25-17250

SPRING

19

708-25-17260

SEAT

20

708-25-17410

PLUG

21

07000-B1009

O-RING

22

07000-B3028

O-RING

23

708-25-17350

COVER

24

708-25-15340

SCREW

25

708-25-15320

BOLT

26

708-25-15320

BOLT

27

01602-20619

WASHER

28

01580-10806

NUT

29

07000-B2012

O-RING

30

07000-B2012

O-RING

31

07001-02012

RING,BACK-UP

32

708-25-15320

BOLT

33

01602-20619

WASHER

34

07000-B2021

O-RING

35

07001-02021

RING,BACK-UP

36

07040-11007

PLUG

37

708-2L-23920

O-RING
