Запчасти Komatsu PC1800-6-M1 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
G-1
707-01-XZ680
CYLINDER GROUP,L.H. (FINAL COATING)
G-1
21T-63-X2350
CYLINDER GROUP,L.H.
G-2
707-01-XZ690
CYLINDER GROUP,R.H. (FINAL COATING)
G-2
21T-63-X2360
CYLINDER GROUP,R.H.
|1
21T-63-02350
CYLINDER ASS'Y
1
21T-63-72740
CYLINDER
2
21T-63-72720
ROD,PISTON
3
707-46-14010
BUSHING
4
21T-72-15850
BUSHING
5
21T-72-15860
BUSHING
6
21T-72-15870
SEAL (KIT)
7
07179-14160
RING,SNAP
8
198-63-93170
SEAL,DUST (KIT)
9
707-27-20630
HEAD,CYLINDER
10
707-51-14080
PACKING,ROD (KIT)
11
07001-05195
RING,BACK-UP (KIT)
12
07000-15195
O-RING (KIT)
13
707-51-14630
RING,BUFFER (KIT)
14
707-52-91150
BUSHING
15
01011-82705
BOLT
16
01643-32780
WASHER
17
707-71-31470
COLLAR
18
707-71-31580
COLLAR
19
707-71-11450
RING
20
707-71-51490
PLUNGER
21
07000-12115
O-RING (KIT)
22
707-35-52860
RING,BACK-UP (KIT)
23
707-36-20300
PISTON
24
707-36-20240
PISTON
25
707-44-20180
RING,PISTON (KIT)
26
707-39-20820
RING,WEAR (KIT)
27
707-44-20910
RING
28
707-40-20860
SPACER
29
01253-61400
BOLT
30
07043-00108
PLUG
31
21T-63-72770
TUBE,L.H.
|31
21T-63-72870
TUBE,R.H.
32
21T-62-88230
TUBE,L.H.
|32
21T-62-88250
TUBE,R.H.
33
707-88-87361
BRACKET
|33
707-88-87360
BRACKET
34
707-88-87370
BRACKET
35
707-88-96110
BAND
36
01010-81240
BOLT
37
01643-31232
WASHER
38
07000-13038
O-RING (KIT)
39
01010-81280
BOLT
40
01643-31232
WASHER
41
07000-13048
O-RING (KIT)
42
01010-81450
BOLT
43
01643-31445
WASHER
44
176-61-41330
CLAMP
45
01010-81250
BOLT
46
01643-31232
WASHER
47
707-88-88480
PLATE
48
01010-81225
BOLT
49
01643-31232
WASHER
50
07283-24346
CLIP
51
01599-01011
NUT
52
01643-31032
WASHER
53
07000-13048
O-RING,(FOR SHIPPING)
54
07378-11410
HEAD,(FOR SHIPPING)
55
07371-51470
FLANGE,(FOR SHIPPING)
56
01010-81455
BOLT,(FOR SHIPPING)
57
01643-31445
WASHER,(FOR SHIPPING)
|58
707-99-77130
SERVICE KIT
Выбрано товаров: 66
