Запчасти Komatsu PC1800-6-M1 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ660

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

21T-63-X2330

CYLINDER GROUP,L.H.

G-2

707-01-XZ670

CYLINDER GROUP,R.H. (FINAL COATING)

G-2

21T-63-X2340

CYLINDER GROUP,R.H.

|1

21T-63-02330

CYLINDER ASS'Y

1

21T-63-62740

CYLINDER

2

21T-63-62720

ROD,PISTON

3

21T-72-15850

BUSHING

4

21T-72-15860

BUSHING

5

21T-72-15870

SEAL,DUST (KIT)

6

07179-14180

RING,SNAP

7

566-63-22241

SEAL,DUST (KIT)

8

707-27-25151

HEAD,CYLINDER

9

707-52-91350

BUSHING

10

707-51-16030

PACKING,ROD (KIT)

11

707-51-16630

RING,BAFFLE (KIT)

12

07000-15250

O-RING (KIT)

13

07001-05250

RING,BACK-UP (KIT)

14

01011-83330

BOLT

15

01643-33380

WASHER

16

707-36-25160

PISTON

17

707-44-25180

RING,PISTON (KIT)

18

707-36-25170

PISTON

19

707-39-25820

RING,WEAR (KIT)

20

707-44-25910

RING

21

707-40-25870

SPACER

22

01253-61615

BOLT

23

07000-15135

O-RING (KIT)

24

707-35-91440

RING,BACK-UP (KIT)

25

707-71-50390

PLUNGER

26

04260-01270

BALL

27

707-71-91380

PIN

28

21T-63-62770

TUBE,L.H.

|28

21T-63-62870

TUBE,R.H.

29

21T-63-62380

TUBE

30

07000-13048

O-RING (KIT)

31

01010-81450

BOLT

32

01643-31445

WASHER

33

21T-62-27890

BRACKET

34

07283-24354

CLIP

35

01599-01011

NUT

36

01643-31032

WASHER

37

01010-81245

BOLT

38

01643-31232

WASHER

39

176-61-41330

CLAMP

40

01010-81250

BOLT

41

01643-31232

WASHER

42

707-88-96620

BRACKET

43

707-88-87300

BRACKET

44

21N-62-18430

BAND

45

01010-81240

BOLT

46

01643-31232

WASHER

47

07000-12060

O-RING (KIT)

48

01011-81645

BOLT

49

01643-31645

WASHER

50

07000-13048

O-RING,(FOR SHIPPING)

51

07378-11410

HEAD,(FOR SHIPPING)

52

07371-51470

FLANGE,(FOR SHIPPING)

53

01010-81455

BOLT,(FOR SHIPPING)

54

01643-31445

WASHER,(FOR SHIPPING)

|55

707-99-85310

SERVICE KIT
