Запчасти Komatsu PC16R-3 МАРКИРОВКА (НАВЕС) (/) МАРКИРОВКА

1

22L-09-R4110

DECAL, DANGER, KEEP OUT WORKING AREA

2

09651-A0481

DECAL, WARNING, READ MANUAL BEFORE OPERATING

3

22L-09-R4140

DECAL, KOMATSU LOGO

4

22L-09-R4160

PLATE, LIFTING POINT

5

21D-98-11860

PLATE, ANCHOR POINT

6

22L-09-R4180

DECAL, UTILITY LOGO

7

22L-98-R2380

DECAL, SYMBOL, STARTING SWITCH CONTROL

8

22L-09-R4190

DECAL, LOCK LEVERS

9

21S-98-33270

DECAL, BALL BEARING RING GREASE POINT

10

21D-98-11220

DECAL, SYMBOL, FUEL

11

21D-98-12040

DECAL, SYMBOL, ELECTRIC SOCKET

12

21D-98-11170

DECAL, SYMBOL, FUEL FILTER

13

21D-98-11230

DECAL, SYMBOL, HYDRAULIC OIL LEVEL

14

21D-98-11180

DECAL, SYMBOL, AIR FILTER

15

21D-98-11190

DECAL, SYMBOL, ENGINE OIL FILTER

16

21D-98-12030

DECAL, SYMBOL, HYDRAULIC OIL

17

21D-98-12050

DECAL, SYMBOL, HYDRAULIC OIL FILTER

18

21D-98-11150

DECAL, SYMBOL, RADIATOR CAP

19

22L-09-R4170

DECAL, SYMBOL, ENGINE COOLANT

20

22L-98-22180

DECAL, WARNING, LOCK LEVERS

21

2A1-98-11190

DECAL, BALANCING POSITION MARK

22

22F-98-33690

DECAL, DANGER, LOCK PIN

23

20W-98-91140

DECAL, PC16R, L.H.

24

20W-98-91110

DECAL, OIL CHART

25

22L-09-R4323

DECAL, FUSES DIAGRAM

26

20W-98-91150

DECAL, WARNING, LOCK LEVERS

27

22L-09-R1520

DECAL, OPERATING

28

20W-98-91510

DECAL, LIFTING CAPACITY

29

09696-50077

MARK PLATE, LPA 77

30

09696-40093

MARK PLATE, LWA 93

31

42N-93-11220

DECAL, DANGER, PINCH POINT

32

22F-98-33640

PLATE, ENGINE OIL FILTER

33

6217-71-6860

DECAL, CAUTION, ENGINE FUEL FILTER

34

09642-A0480

PLATE, INSTRUCTION, COOLANT

35

22F-98-33630

DECAL, CAUTION, PRESSURISE THE TANK

36

09659-A057B

PLATE, WARNING, ACCUMULATOR
