Запчасти Komatsu PC16R-3 ТОПЛИВН. ФОРСУНКА ДВИГАТЕЛЬ БЛОК

\0

22J-01-R5201

ENGINE, ASSEMBLY

\0

KT16001-5300-0

NOZZLE, SUBASSEMBLY

1

KT15841-9203-0

NUT

2

KT15841-5323-0

SHIM, 0.900 MM

3

KT15841-5317-0

SPRING, NOZZLE

4

KT15841-5335-0

GASKET

5

KT15841-5316-0

PISTON

6

KT16475-5328-0

NUT

7

KT15841-9404-0

WASHER

8

KT16851-5361-0

PISTON

\8

KT15841-9810-0

KIT, SHIM

9

KT15841-5323-0

SHIM, 0.900 MM

9

KT15841-9851-0

SHIM, 0.925 MM

9

KT15841-9852-0

SHIM, 0.950 MM

9

KT15841-9853-0

SHIM, 0.975 MM

9

KT15841-9854-0

SHIM, 1.000 MM

9

KT15841-9855-0

SHIM, 1.025 MM

9

KT15841-9856-0

SHIM, 1.050 MM

9

KT15841-9857-0

SHIM, 1.075 MM

9

KT15841-9858-0

SHIM, 1.100 MM

9

KT15841-9859-0

SHIM, 1.125 MM

9

KT15841-9860-0

SHIM, 1.150 MM

9

KT15841-9861-0

SHIM, 1.175 MM

9

KT15841-9862-0

SHIM, 1.200 MM

9

KT15841-9863-0

SHIM, 1.225 MM

9

KT15841-9864-0

SHIM, 1.250 MM

9

KT15841-9865-0

SHIM, 1.275 MM

9

KT15841-9866-0

SHIM, 1.300 MM

9

KT15841-9867-0

SHIM, 1.325 MM

9

KT15841-9868-0

SHIM, 1.350 MM

9

KT15841-9869-0

SHIM, 1.375 MM

9

KT15841-9870-0

SHIM, 1.400 MM

9

KT15841-9871-0

SHIM, 1.425 MM

9

KT15841-9872-0

SHIM, 1.450 MM

9

KT15841-9873-0

SHIM, 1.475 MM

9

KT15841-9874-0

SHIM, 1.500 MM

9

KT15841-9875-0

SHIM, 1.525 MM

9

KT15841-9876-0

SHIM, 1.550 MM

9

KT15841-9877-0

SHIM, 1.575 MM

9

KT15841-9878-0

SHIM, 1.600 MM

9

KT15841-9879-0

SHIM, 1.625 MM

9

KT15841-9880-0

SHIM, 1.650 MM

9

KT15841-9881-0

SHIM, 1.675 MM

9

KT15841-9882-0

SHIM, 1.700 MM

9

KT15841-9883-0

SHIM, 1.725 MM

9

KT15841-9884-0

SHIM, 1.750 MM

9

KT15841-9885-0

SHIM, 1.775 MM

9

KT15841-9886-0

SHIM, 1.800 MM

9

KT15841-9887-0

SHIM, 1.825 MM

9

KT15841-9888-0

SHIM, 1.850 MM

9

KT15841-9889-0

SHIM, 1.875 MM

9

KT15841-9890-0

SHIM, 1.900 MM

9

KT15841-9891-0

SHIM, 1.925 MM

9

KT15841-9892-0

SHIM, 1.950 MM
