Запчасти Komatsu PC16R-3 ГИДР. НАСОС. РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0.99

20W-60-91401

HYDRAULIC PUMP, ASSEMBLY

1

FUFZD4732103

SHAFT

2

FUCB852012

COLLAR

3

FUFZD4726110

PLATE

4

840141021

BALL

5

FUFZD4802115

SPRING

6

FUPS24201000

SPRING, GUIDE

7

FUFZD4726119

SPRING, GUIDE

8

FUPS13101000

PIN

9

FUFZD4984125

BUSHING

10

FU6004

BEARING

11

FUFZD4984133

SCREW

12

FURH42

RING, SNAP

13

FUTH10X40

BOLT

14

840141035

PLUG

15

FUPPSW5X12

PIN, SPRING

16

840141041

SCREW

17

FUNHA8

NUT

18

BODY, PUMP

19

BODY

20

BEARING

21

FUWD8X16X2.0

WASHER

\21.99

CYLINDER BARREL, ASSEMBLY

22

FUFZD4726104

CYLINDER BARREL

23

PLATE, VALVE

24

PISTON

25

FUFZS2610092

HOLDER

26

NEEDLE

27

SPRING

28

FUPS29101000

RETAINER

29

FURH28

RING, SNAP

30

SHOE

31

RETAINER, SHOE

32

FUFZD4027661

COUPLING

33

FUTH-8X20

BOLT

34

FUWGA8

WASHER

\34.99

FUPDDS-109800

KIT, GASKET

35

FUFZD4726113

GASKET

36

SEAL, OIL

37

FUROP1190

O-RING

38

FUWD8X16X2.0

WASHER

39

O-RING

40

FUROP890

O-RING

41

FU7054101041K

PUMP, ASSEMBLY
