Запчасти Komatsu PC16R-3 КОЖУХ ШЕСТЕРЕН. ПЕРЕДАЧИ ДВИГАТЕЛЬ БЛОК

\0

22J-01-R5201

ENGINE, ASSEMBLY

\0

KT17529-0402-5

GEAR HOUSING, ASSEMBLY

1

KT15521-9603-0

PLUG

2

KT15841-5628-0

PIN

3

KT1G639-3288-0

COVER

4

KT16259-3290-0

BOLT

5

KT04814-50600

O-RING

6

KT04814-00150

O-RING

7

KT15241-3229-0

JOINT

8

KT16851-3695-0

SPRING

9

KT15841-3693-0

SEAT, SPRING

10

KT07715-03211

BALL

11

KT16871-0413-0

GASKET

12

KT01023-50618

BOLT

13

KT01023-60650

BOLT

14

KT15841-9101-0

BOLT

15

KT01023-50660

BOLT

16

KT01023-60670

BOLT

17

KT01023-50680

BOLT

18

KT17563-9101-0

BOLT

19

KT15877-0414-0

SEAL OIL

20

KT19461-8334-0

COVER

21

KT19461-8813-2

GASKET

22

KT15221-8821-0

STUD

23

KT02751-50060

NUT

24

KT1G386-3314-0

PLUG

25

KT04817-50300

O-RING

26

KT19090-1131-0

FLANGE

27

KT19483-3312-3

GASKET

28

KT01023-60650

BOLT

29

KT01023-50618

BOLT
