Запчасти Komatsu PC16R-3 HS СТАРТЕР (/) ДВИГАТЕЛЬ БЛОК

\0

22J-01-R5201

ENGINE, ASSEMBLY

\0

KT16285-6301-0

STARTER MOTOR

1

KT11460-6308-0

YOKE

2

KT11460-6307-0

ROTOR, ASSEMBLY

3

KT11460-6350-0

BEARING

4

KT11460-6353-0

BEARING

5

KT16285-6304-0

FAST COUPLING, ASSEMBLY

6

KT11460-6311-0

RETAINER

7

KT11460-6327-0

GEAR

8

KT16285-6303-0

HOUSING, ASSEMBLY

9

KT16285-6320-0

FRAME, ASSEMBLY

10

KT11470-6338-0

HOLDER ASSEMBLY, BRUSH

11

KT11460-6339-0

SPRING

12

KT16285-6302-0

SWITCH ASSEMBLY, MAGNETIC

13

KT15511-6376-0

BOLT, ASSEMBLY

14

KT19212-6310-0

ROLLER

15

KT11460-9331-0

BOLT

16

KT19212-9713-0

BALL

17

KT11460-6332-0

BOLT

18

KT11460-6312-0

SPRING

19

KT15511-9666-0

O-RING

20

KT16285-6357-0

PIPE

21

KT13963-9201-0

NUT

22

KT16285-9201-0

NUT

23

KT11173-6313-0

COVER
