Запчасти Komatsu PC16R-3 HS МОТОР ХОДА (/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

Схема запчастей Komatsu PC16R-3 HS - МОТОР ХОДА (/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА
31
54
29
51
32
38
35
40
35
39
35
40
34
40
33
36
19
35
42
50
26
24
30
51
18
25
41
43
38
48
20
57
35
35
56
41
44
27
40
32
42
49
36
55
33
50
44
16
58
35
8
14
7
46
12
47
9
15
10
17
59
53
13
37
22
11
45
22
37
5
23
34
28
39
6
52
21
3
28
2
23
29
31
4
1

Артикул

Название

Примечание

Количество

\0

20W-60-91501

TRAVEL MOTOR, ASSEMBLY

\0

FUMHB28517

BODY, SUBASSEMBLY

1

BODY

2

PISTON

3

SEAL, OIL

4

PLUG

\4

FUMVN101037

SHAFT, SUBASSEMBLY

5

SHAFT

6

FU16004

BEARING

\6

FUMHCB14841

CYLINDER BARREL, SUBASSEMBLY

7

CYLINDER BARREL

8

PLATE

9

PISTON

10

SHOE

11

SHOE HOLDER

12

BARREL HOLDER

13

PIN

14

SPRING

15

RETAINER

16

840141019

RING, SNAP

17

FUMV68101T43

SWASH PLATE

\17

FUMHB07BAC4244

BODY, SUBASSEMBLY

18

FU6201

BEARING

19

840141038

SPRING PIN

20

BODY

21

SPOOL

22

CHECK VALVE

23

GUIDE, SPRING

24

SPOOL

25

SPOOL

26

SPOOL

27

SPOOL

28

SPRING

29

SPRING

30

SPRING

31

PLUG

32

PLUG

33

PLUG

34

RING

35

PLUG

36

FUROP1890

O-RING

37

O-RING

38

FUROP1490

O-RING

39

FUROP1890

O-RING

40

CHOKE

41

CHOKE

42

NEEDLE

\42

FUMVS20200P

KIT, GASKET

43

FUROG10590

O-RING

44

FUROP690

O-RING

45

SEAL, OIL

46

FUROG9590

O-RING

47

FUROG9090

O-RING

48

FURBOG95

RING, BACK-UP

49

FURBOG90

RING, BACK-UP

50

FUROP890

O-RING

51

FUROP1490

O-RING

52

FUROP1890

O-RING

53

FUYB15/32

BALL

54

FUTH-8X20

BOLT

55

FUPPH76X14

PIN

56

FUFZS2082282

PISTON, BRAKE

57

FUFZS2082291

SPRING

58

FUFZD4679136

DISK

59

FUFZS2082372

DISK

Выбрано товаров: 65
