Запчасти Komatsu PC16R-2 ГЕНЕРАТОР ДВИГАТЕЛЬ

\0

22J-01-R5101

ENGINE, ASSY.

1

KT1K574-6401-5

ALTERNATOR, ASSY.

2

KT15881-6411-0

PULLEY

3

KT15881-9201-0

NUT

4

KT15881-6415-0

COLLAR

5

KT66436-6404-0

ROTOR

6

KT15881-6480-0

COVER

7

KT16652-6477-0

BEARING

8

KT15881-6481-0

GASKET

9

KT66436-6402-0

STATOR

10

KT15881-6471-0

PLATE

11

KT15881-9301-0

SCREW

12

KT15881-6426-0

BOLT

13

KT16652-6478-0

BEARING

14

KT16678-6406-0

STATOR

15

KT16678-6423-0

COVER

16

KT15881-6485-0

COVER

17

KT15881-6490-0

BUSHING

18

KT16652-6431-0

FLEX HORN

19

KT15881-6409-0

FLEX HORN

20

KT15881-6433-0

SPRING

21

KT15881-9302-0

SCREW

22

KT15881-9303-0

SCREW

23

KT15881-9304-0

SCREW

24

KT15881-9104-0

BOLT

25

KT15881-9202-0

NUT

26

KT15881-9105-0

BOLT

27

KT14182-9203-0

NUT

28

KT1K574-6460-0

HOLDER BRUSH, ASSY.
