Запчасти Komatsu PC16R-2 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

\0

22J-01-R5101

ENGINE, ASSY.

1

KT1E051-7270-0

FLANGE, ASSY.

2

KT16241-7337-0

PIPE

3

KT16222-8304-0

TEMPERATURE TRANSMITTER

4

KT15841-7292-3

GASKET

5

KT1A021-9602-0

PLUG

6

KT01023-50616

BOLT

7

KT01023-60650

BOLT

8

KT16851-7335-0

PIPE

9

KT16241-7336-0

CLAMP

10

KT19434-7301-4

THERMOSTAT

11

KT1E051-4326-0

COVER

12

KT16221-7327-0

GASKET

13

KT01123-50825

BOLT

14

KT1G386-7303-0

WATER PUMP

15

KT15852-7352-0

FLANGE

16

KT15852-7355-0

BEARING

17

KT15481-7305-0

GASKET

18

KT19883-7351-0

FAN

19

KT15852-7334-0

PIPE

20

KT15881-7343-2

GASKET

21

KT01023-50622

BOLT

22

KT01023-50638

BOLT

23

KT19028-7286-0

PIPE

24

KT15881-7287-0

PIPE

25

KT15841-9151-0

STUD

26

KT02751-50060

NUT

27

KT15841-7296-0

CLAMP

28

KT06311-55010

PLUG

29

KT04724-00100

GASKET

30

KT16219-7411-0

FAN

31

KT16241-7425-0

PULLEY

32

KT15876-7415-2

COLLAR

33

KT01754-50620

BOLT
