Запчасти Komatsu PC160LC-8 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА 6774 275

|$1

21K-27-00122

FINAL DRIVE ASS'Y

|$2

20Y-27-00110

FLOATING SEAL ASS'Y

1

SEAL

2

O-RING

3

20Y-27-41140

HUB,GEAR

4

20Y-27-41320

BEARING

5

20Y-27-41190

NUT,LOCK

6

20Y-27-41180

LOCK

7

01010-81020

BOLT

8

20Y-27-41151

CARRIER

9

20Y-27-41130

GEAR

10

20Y-27-41250

BEARING

11

20Y-27-41270

WASHER,THRUST

12

20Y-27-41170

PIN

13

20Y-27-21290

PIN

14

20Y-27-13310

THRUST WASHER

15

20Y-27-41120

GEAR

16

20Y-27-22240

THRUST WASHER

17

20Y-27-31111

CARRIER

18

20Y-27-22120

GEAR

19

20Y-27-22210

BEARING

20

20Y-27-21240

THRUST WASHER

21

20Y-27-21220

PIN

22

20Y-27-21280

PIN

23

20Y-27-41110

SHAFT

24

20Y-27-21310

THRUST WASHER

25

20Y-27-41160

COVER

26

04260-01587

BALL

27

01010-81240

BOLT

28

01643-31232

WASHER

29

07049-01012

PLUG

30

20Y-27-31190

PLUG

31

07002-12434

O-RING

32

20Y-27-D3060

SPROCKET

33

20Y-27-11561

BOLT

34

01010-61660

BOLT

35

01643-31645

WASHER

36

20Y-30-21192

COVER

37

01010-81230

BOLT

38

01643-31232

WASHER
