Запчасти Komatsu PC160LC-8 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА (ВНУТР. ЧАСТИ )(/) 6774 275

|$1

21K-27-00122

FINAL DRIVE ASS'Y

|$2

708-8F-00270

MOTOR ASS'Y

1

708-8F-32121

SHAFT

2

708-8F-12151

BEARING

3

708-7L-12140

BEARING

4

708-7L-05010

SPACER KIT

|$7

SPACER, T=1.5MM

|$8

SPACER, T=1.6MM

|$9

SPACER, T=1.7MM

|$10

SPACER, T=1.8MM

|$11

SPACER, T=1.9MM

|$12

SPACER, T=2.0MM

5

706-7G-11291

OIL SEAL

6

708-8F-12230

SPACER, T=3.2MM

7

04065-07225

RING

8

708-8F-33121

CYLINDER BLOCK

9

708-8F-33230

PLATE,VALVE

10

720-68-19610

PIN

11

708-8F-33360

PIN

12

708-7L-13140

SEAT

13

708-8F-33160

SPRING

14

04065-04818

RING

15

708-8F-33350

RETAINER,GUIDE

16

708-2L-33350

RETAINER,SHOE

17

708-8F-33310

PISTON SUB ASS'Y

18

708-8F-33490

CAM,ROCKER

19

708-8F-33710

BALL,RETAINER

20

708-8F-34141

PISTON

21

708-8F-34240

SPRING

22

708-8F-34250

SPRING

23

708-8F-35220

PLATE

24

708-8F-35230

PLATE

25

708-8F-35120

DISC

26

708-8F-35140

PISTON,BRAKE

27

708-8F-35160

O-RING

28

708-8F-35170

RING,BACK-UP

29

708-8F-35180

O-RING

30

708-8F-35190

RING,BACK-UP

31

708-8F-35150

SPRING

32

04025-00324

SPRING PIN
