Запчасти Komatsu PC160LC-8 КАБИНА (ПОЛ)(КОНСОЛЬ, R.H) K

1

20Y-43-41314

FRAME R.H

2

01010-D1230

BOLT

3

01643-71232

WASHER

4

20Y-43-41631

SHEET

5

22U-43-23251

SHEET

6

22U-43-23290

CLIP

7

20Y-43-41324

COVER (R.H/UPPER)

8

20Y-43-41661

SHEET

9

01010-80616

BOLT

10

01643-30623

WASHER

11

20Y-43-41290

COLLAR

12

20Y-43-41332

COVER (R.H/FRONT)

13

01245-00616

SCREW

14

01643-70623

WASHER

15

01010-80616

BOLT

16

01643-30623

WASHER

17

01435-00612

BOLT

18

20Y-43-41290

COLLAR

19

20Y-43-41353

COVER (R.H/REAR)

20

01245-00616

SCREW

21

01643-70623

WASHER

22

20Y-43-41290

COLLAR

23

01245-00616

SCREW

24

01643-70623

WASHER

25

09415-02512

CAP

26

08086-20000

SWITCH, STARTING

27

20Y-43-41740

PLATE

28

20Y-43-41750

WASHER

29

20Y-43-41790

WASHER

30

20Y-43-41671

SHEET

31

08034-20519

BAND

32

22U-06-22380

POTENTIOMETER

33

22U-06-22460

SPRING

34

KNOB

35

20Y-06-42110

SWITCH (SWING LOCK)

36

20Y-06-42121

SWITCH (LIGHT)

37

20Y-06-42190

COVER

38

20Y-06-41130

WIRING HARNESS

39

08034-20414

BAND

40

01023-10508

SCREW

41

01601-20513

WASHER

42

22U-43-23260

CLIP

43

04434-51710

CLIP

44

01010-81016

BOLT

45

01643-31032

WASHER
