Запчасти Komatsu PC160LC-8 КАБИНА (ПОЛ)(КЛАПАН PPCДЛЯ ХОД)(/) K

|$1

702-16-04250

PILOT VALVE

1

702-16-73660

BODY, VALVE

2

702-16-53120

VALVE

3

702-16-51140

SHIM, T=0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

702-16-73630

CASE

11

702-16-57350

LEVER

12

702-16-73550

SHAFT

13

702-16-73640

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

702-16-54331

WASHER

|$19

702-16-54341

WASHER

|$20

702-16-54351

WASHER

|$21

702-16-56380

WASHER

|$22

702-16-56390

WASHER

18

04025-00432

SPRING PIN

19

702-16-54430

BUSHING

20

07000-12018

O-RING

21

702-16-73610

DAMPER ASS'Y

22

01023-10306

SCREW

23

702-16-73650

PLATE

24

04022-04016

SPRING PIN
