Запчасти Komatsu PC160LC-8 КАБИНА (ПЕРЕДН. ОКНА) K

|$1

21K-53-00121

CAB ASS'Y (WITH AC)

|$2

21K-53-00190

CAB ASS'Y (WITHOUT AC)

|$3

20Y-53-00031

FRONT WINDOW ASS'Y

1

20Y-53-11511

FRONT FRAME

2

20Y-53-11520

GLASS

3

20Y-54-51531

SEAL

4

20Y-53-11551

SEAL

5

22B-54-15411

LOCK ASS'Y (L.H)

6

22B-54-15440

CASE (L.H)

7

22B-54-15470

CASE (L.H)

8

22B-54-15421

LOCK ASS'Y (R.H)

9

22B-54-15450

CASE (R.H)

10

22B-54-15480

KNOB (R.H)

11

01010-D0816

BOLT

12

418-54-35450

WASHER

13

20Y-54-52621

ROLLER

14

20Y-54-52681

ROLLER

15

20Y-53-12330

PIN (L.H/UNDER)

16

20Y-54-14590

HANDLE

17

01245-00616

SCREW

18

01643-70623

WASHER

19

20Y-53-12830

BRACKET (UNDER)

20

01245-00816

SCREW

21

01643-70823

WASHER

22

20Y-54-51670

STOPPER

23

20Y-54-51680

STOPPER

24

01252-80616

BOLT

25

01643-70623

WASHER

26

20Y-53-11561

BLOCK LH ASS'Y

27

01245-00816

SCREW

28

01643-70823

WASHER

29

20Y-53-11661

BRACKET (R.H)

30

01245-00816

SCREW

31

01643-70823

WASHER

32

21J-06-12440

SWITCH

33

01583-11811

NUT

34

20Y-53-11581

BRACKET

35

20Y-53-11641

BRACKET

36

01435-00612

BOLT

37

20Y-54-11611

STOPPER

38

01580-11008

NUT

39

20Y-54-51621

STRIKER

40

01584-31008

NUT

41

01643-71032

WASHER

42

20Y-53-11540

TRIM SEAL
