Запчасти Komatsu PC160LC-8 СТАРТЕР, .KW КОМПОНЕНТЫ ДВИГАТЕЛЯ

|1

600-863-4210

Starting Motor Assembly, 4.5Kw

1

ND028100-2882

Yoke Assembly

2

ND028062-0130

Cover

3

ND028099-3570

Starting Motor Kit

4

ND028200-1590

Armature Assembly

5

ND949100-1930

Bearing, Ball

6

ND949100-1750

Bearing, Ball

|6

ND028300-6551

Clutch Assembly

7

ND028099-3270

Starting Motor Kit

8

ND028300-6751

Clutch Assembly

9

ND949100-4500

Bearing, Ball

10

ND949100-1920

Bearing, Ball

11

ND949170-4040

Spring

12

ND028381-0071

Shaft

13

ND228401-0633

Housing Assembly

14

ND153400-8530

Switch Assembly

15

ND028099-5620

Starting Motor Kit

16

ND028099-3160

Starting Motor Kit

17

ND053660-7170

Plunger

18

ND053404-0240

Gasket

19

ND053505-0290

Cover

20

ND053480-7560

Bolt Assembly

21

ND028065-0250

Bushing

22

ND028510-5390

Holder Assembly, Brush

23

ND949173-0571

Spring

24

ND028501-8091

Frame

25

ND128961-0010

Ball

26

ND949170-4070

Spring

27

ND028371-1500

Pinion

28

ND028306-0070

Roller

29

ND028063-0030

Retainer

30

ND028327-0171

Retainer

31

ND128950-0520

Bolt

32

ND949020-0600

Washer

33

ND90801-10050

O-ring

34

ND949007-6530

Screw

35

ND90170-10061

Nut

36

ND949056-4480

Nut

37

ND90258-10001

Washer

38

ND949006-4720

Screw

39

ND90200-06241

Washer

40

ND028062-5790

Cover

41

ND949007-6850

Screw

42

ND028901-5190

Seal
