Запчасти Komatsu PC160LC-7K 2-СЕКЦИОНН. СТРЕЛА (2-Я СТРЕЛА И ПАЛЕЦ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21K-966-K222

BOOM ASS'Y, SECOND

1

07145-00080

SEAL

2

21K-70-71311

BUSHING

3

21K-966-K171

BOOM, FIRST

4

01572-21019

SEAT (WELDED)

5

01572-21225

SEAT (WELDED)

6

08036-D1630

CLIP (WELDED)

7

20E-70-K1510

SEAT (WELDED)

8

21K-70-31280

SEAT (WELDED)

9

566-16-11240

BOSS (WELDED)

10

207-70-61220

PIN

11

207-70-71280

SPACER¤ 1.0MM

12

205-70-66580

PLATE

13

01010-81230

BOLT

14

01643-31232

WASHER

15

20Y-70-11180

PIN

16

20Y-70-31431

SPACER¤ 1.0MM

|16

20Y-70-31430

SPACER¤ 1.0MM

17

206-70-71451

SPACER¤ 2.0MM

|17

206-70-71450

SPACER¤ 2.0MM

18

205-70-66580

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

21K-70-71180

PIN

22

21K-70-71411

SPACER¤ 2.0MM

|22

21K-70-71410

SPACER¤ 2.0MM

23

21K-70-71421

SPACER¤ 2.5MM

|23

21K-70-71420

SPACER¤ 2.5MM

24

21K-70-71431

SPACER¤ 3.0MM

|24

21K-70-71430

SPACER¤ 3.0MM

25

205-70-7130

PLATE

26

01010-81235

BOLT

27

01643-31232

WASHER
