Запчасти Komatsu PC160LC-7E0 ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XN520

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0L500

CYLINDER ASS'Y

1

707-13-10530

CYLINDER

2

721-58-70160

ROD,PISTON

3

21K-70-71320

BUSHING

4

07145-00070

SEAL,DUST (KIT)

5

07020-00000

FITTING,GREASE

6

707-76-70370

BUSHING

7

20Y-70-23220

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-10750

HEAD,CYLINDER

10

144-63-95170

SEAL,DUST (KIT)

11

07179-12084

RING,SNAP

12

707-51-70030

PACKING,ROD (KIT)

13

707-51-70650

RING,BUFFER (KIT)

14

707-52-90470

BUSHING

15

707-75-70110

RING,SNAP

16

07000-15095

O-RING (KIT)

17

707-35-91060

RING,BACK-UP (KIT)

18

01010-81465

BOLT

19

01643-51445

WASHER

20

707-36-10760

PISTON

21

707-44-10250

RING,PISTON (KIT)

22

707-39-10550

RING,WEAR (KIT)

23

707-44-10911

RING

24

01310-01216

SCREW

25

707-34-60030

O-RING (KIT)

26

707-35-90730

RING (KIT)

27

707-86-47390

TUBE

28

02896-61015

O-RING (KIT)

29

707-88-22940

BRACKET

30

707-88-21650

BAND

31

07372-21035

BOLT

32

01643-51032

WASHER

33

07283-32236

CLIP

34

01597-01009

NUT

35

01643-31032

WASHER

36

01010-80850

BOLT

37

01643-50823

WASHER

38

07000-13025

O-RING (KIT)

|$43

707-99-37150

SERVICE KIT
