Запчасти Komatsu PC160LC-7 ГИДРАВЛ МОТОР ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21K-26-B7300

HYDRAULIC MOTOR

1

21K-26-B7310

MOTOR HOUSING (K0)

2

PLUG (K1.4)

3

O-RING (K1.4)

4

21K-26-B7420

MOTOR SEAL RING (K5)

5

BEARING (K6)

6

21K-26-B7410

MOTOR SHAFT ASS'Y (K4)

|7

21K-26-B7390

CYLINDER BLOCK ASS'Y (K2)

7

THRUST PLATE

8

PISTON

9

RETAINER PLATE

10

SPHERICAL BUSH

11

PIN

12

CYLINDER BLOCK

13

COLLAR

14

SPRING

15

COLLAR WASHER

16

CIRCLIP

17

VALVE PLATE

18

STEEL DISC (K7)

19

BRAKE DISC (K7)

20

O-RING (K8)

21

BRAKE SPACER (K7)

22

O-RING (K8)

23

O-RING (K8)

24

BRAKE PISTON (K7)

25

SPRING (K7)

26

SPRING (K7)

27

O-RING (K8)

28

BEARING (K6)

29

PIN (K7)

|30

21K-26-B7320

BASE PLATE ASS'Y (K1)

30

PIN

31

21K-26-B7330

BASE PLATE

32

21K-26-B7350

RELIEF VALVE (ITEMS 33 TO 47) (K1.5A)

|32

21K-26-B7360

RELIEF VALVE (ITEMS 33 TO 47) (K1.5B)

33

NUT

34

SCREW

35

PLUG

36

O-RING (K8)

37

O-RING (K8)

38

SEAT

39

SPRING

40

SEAT SPRING

41

SLEEVE

42

O-RING (K8)

43

RING BACK-UP

44

VALVE

45

SEAT VALVE

46

RING BACK-UP

47

O-RING (K8)

|48

21K-26-B7370

ANTICAVIT.VALVE

48

CHECK VALVE

49

SPRING

50

O-RING (K8)

51

PLUG

52

SCREW

53

PLUG

54

O-RING (K1.4

|55

21K-26-B7380

ANTISWING BACK VALVE ASS'Y (K1.9)

55

ANTISWING BACK VALVE

56

PLUG (K1.4)

57

O-RING (K1.4

58

PLUG

59

O-RING (K8)

60

SPRING

61

PISTON

62

VALVE

63

PLUG

64

PLUG

65

O-RING (K8)

66

O-RING (K8)

67

SCREW

K1.4

21K-26-B7340

MOTOR SHAFT ASS'Y

K6

21K-26-B7430

BEARING ASS'Y

K7

21K-26-B7440

BRAKE ASS'Y

K8

21K-26-B7450

SEALS ASS'Y
