Запчасти Komatsu PC160LC-7 ОХЛАЖД-Е (NET И КОЖУХ) (№B-B99) СИСТЕМА ОХЛАЖДЕНИЯ

1

21K-03-71421

NET

2

01434-10616

BOLT¤ WING

3

01643-30623

WASHER

4

21K-03-71431

NET

5

01434-10616

BOLT¤ WING

6

01643-30623

WASHER

7

21K-03-71371

SHROUD

8

21K-03-71541

SHEET

9

01010-81020

BOLT

10

01643-31032

WASHER

|11

21K-03-71830

COVER

11

COVER

12

21K-03-71511

SHEET

13

21K-03-71521

SHEET

14

01010-81020

BOLT

15

01643-31032

WASHER

|16

21K-03-71840

COVER

16

COVER

17

21K-03-71561

SHEET

18

01010-81020

BOLT

19

01643-31032

WASHER

20

21K-03-71380

PLATE

21

01010-81020

BOLT

22

01643-31032

WASHER

23

21K-03-71331

TUBE

24

01010-81245

BOLT

25

01643-31232

WASHER

26

07283-34346

CLIP

27

01643-31032

WASHER

28

01597-01009

NUT

29

21K-03-71341

TUBE

30

01010-81245

BOLT

31

01643-31232

WASHER

32

21K-03-71351

BRACKET

33

01010-81020

BOLT

34

01643-31032

WASHER

35

21K-03-71361

BRACKET

36

01010-81020

BOLT

37

01643-31032

WASHER

38

21K-03-71152

AFTER COOLER

|38

21K-03-71151

AFTER COOLER

39

01010-81020

BOLT

40

01643-31032

WASHER

41

20Y-979-6131

CONDENSER ASS'Y

42

01010-80820

BOLT

43

01643-30823

WASHER

44

20Y-03-21390

HOSE

|44

20Y-03-12220

HOSE

45

206-03-43340

CLIP
