Запчасти Komatsu PC160LC-7 ОСНОВНАЯ РАМА (C АНТИКОР. ЭЛЕМЕНТОМ)(№-) ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

21K-46-71400

FRAME

2

205-30-71181

COVER

3

205-30-71191

GASKET

4

01010-81230

BOLT

5

01643-31232

WASHER

6

21K-46-71160

SHEET

7

21K-46-71210

SHEET

8

21K-46-71220

SHEET

9

21K-46-71230

SHEET

10

21K-46-71241

SHEET

11

21K-46-71291

SHEET

|$17

21K-46-71310

COVER

12

PLATE

13

21K-46-71260

SHEET

14

21K-46-71330

SEAL

|$22

21K-46-71320

COVER

15

PLATE

16

21K-46-71280

SHEET

17

21K-46-71340

SEAL

18

01010-81230

BOLT

19

01643-31232

WASHER

20

21K-46-71350

SHEET

|$32

20Y-46-42411

COVER

21

COVER

22

20Y-46-42231

SEAL

23

20Y-46-42460

SHEET

|$37

20Y-46-42422

COVER

24

COVER

25

20Y-46-42251

SEAL

26

20Y-46-42460

SHEET

27

20Y-46-42470

SEAL

28

20Y-46-42480

SEAL

|$44

20Y-46-42431

COVER

29

COVER

30

20Y-46-42241

SEAL

31

20Y-46-42460

SHEET

32

20Y-46-42490

SEAL

|$50

20Y-46-42440

COVER

33

COVER

33

COVER

34

20Y-46-42260

SHEET

35

20Y-46-42210

SEAL

36

20Y-46-42310

SHEET

37

20Y-46-42320

SHEET

38

20Y-46-42330

SHEET

39

20Y-46-42340

SHEET

40

20Y-46-42350

SHEET

41

20Y-46-42360

SHEET

42

20Y-46-42370

SHEET

43

01010-81035

BOLT

44

01643-31032

WASHER

45

01010-81225

BOLT

46

01643-31232

WASHER

47

21K-46-71180

GROMMET

48

206-46-71180

GROMMET

49

20Y-43-11281

GROMMET

50

20X-06-31130

GROMMET
