Запчасти Komatsu PC160LC-7 ЦИЛИНДР РУКОЯТИ(СИСТЕМА СМАЗКИ 100 ЧАС.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS170

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0E510

CYLINDER ASS'Y

1

707-13-12340

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-85310

ROD,PISTON

5

707-27-12921

HEAD,CYLINDER

6

07179-13099

RING,SNAP

7

707-56-85510

SEAL,DUST (KIT)

8

707-52-90610

BUSHING

9

707-51-85030

PACKING,ROD (KIT)

10

07000-15110

O-RING (KIT)

11

707-35-91220

RING,BACK-UP (KIT)

12

707-51-85640

RING,BUFFER (KIT)

13

01010-81670

BOLT

14

01643-51645

WASHER

15

707-36-12851

PISTON

16

707-44-12180

RING,PISTON (KIT)

17

707-39-12140

RING,WEAR (KIT)

18

707-44-12911

RING

19

707-71-70820

PLUNGER

20

07000-15075

O-RING (KIT)

21

707-35-90930

RING,BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-80230

PLUNGER

24

07020-00000

FITTING,GREASE

25

707-71-34640

COLLAR

26

707-35-91220

RING,BACK-UP (KIT)

27

07000-15110

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

30

707-83-13010

VALVE

31

07750-01628

SPRING

32

707-87-14070

PLUG

33

07002-12034

O-RING (KIT)

34

707-86-66770

TUBE

35

07372-21060

BOLT

36

01643-51032

WASHER

37

07372-21045

BOLT

38

01643-51032

WASHER

39

07000-13030

O-RING (KIT)

40

707-88-22930

BRACKET

41

707-88-21620

BAND

42

707-88-22970

BRACKET

43

707-88-21630

BAND

44

07372-21035

BOLT

45

01643-51032

WASHER

46

07283-32738

CLIP

47

01597-01009

NUT

48

01643-31032

WASHER

49

02896-61018

O-RING (KIT)

|$54

707-99-46320

SERVICE KIT
