Запчасти Komatsu PC160LC-7 ЦИЛИНДР СТРЕЛЫ(СИСТЕМА СМАЗКИ 100 ЧАС.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS150

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XS160

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0H360

CYLINDER ASS'Y

1

707-13-11160

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-75650

ROD,PISTON

6

707-76-70230

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

707-27-11720

HEAD,CYLINDER

9

07179-13089

RING,SNAP

10

144-63-94170

SEAL,DUST (KIT)

11

707-52-90500

BUSHING

12

707-51-75030

PACKING,ROD (KIT)

13

07000-15100

O-RING (KIT)

14

707-35-91130

RING,BACK-UP (KIT)

15

707-51-75640

RING,BUFFER (KIT)

16

01010-81670

BOLT

17

01643-51645

WASHER

18

721-36-11020

PISTON

19

707-44-11180

RING,PISTON (KIT)

20

707-39-11150

RING,WEAR (KIT)

21

707-44-11911

RING

22

707-71-70810

PLUNGER

23

07000-15070

O-RING (KIT)

24

707-35-90360

RING,BACK-UP (KIT)

25

01310-01216

SCREW

26

707-71-34400

COLLAR

27

707-35-91130

RING,BACK-UP (KIT)

28

07000-15100

O-RING (KIT)

29

707-86-47400

TUBE,L.H.

29

707-86-47410

TUBE,R.H.

30

707-86-66780

TUBE,L.H.

30

707-86-66790

TUBE,R.H.

31

01010-80845

BOLT

32

01643-50823

WASHER

33

07372-21060

BOLT

34

01643-51032

WASHER

35

07372-21045

BOLT

36

01643-51032

WASHER

37

07000-13025

O-RING (KIT)

38

07000-13030

O-RING (KIT)

39

707-88-22910

BRACKET,L.H.

39

707-88-22920

BRACKET,R.H.

40

707-88-21640

BAND

41

07372-21035

BOLT

42

01643-51032

WASHER

43

07283-32236

CLIP

44

07283-32738

CLIP

45

01597-01009

NUT

46

01643-31032

WASHER

47

02896-61015

O-RING (KIT)

48

02896-61018

O-RING (KIT)

|$58

707-99-38720

SERVICE KIT
