Запчасти Komatsu PC160LC-7 ОСНОВНАЯ РАМА (С ЗАЩИТА НИЖНЕЙ ЧАСТИ)(№-) ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

21K-46-71500

FRAME

2

21K-46-72B60

PLATE (WELDED)

3

21K-46-72B70

PLATE (WELDED)

4

21K-46-72B80

PLATE (WELDED)

5

21K-46-72B90

PLATE (WELDED)

6

21K-46-73B40

PLATE (WELDED)

7

21K-46-72B80

PLATE (WELDED)

8

21K-46-72B90

PLATE (WELDED)

9

205-30-71181

COVER

10

205-30-71191

GASKET

11

01010-81230

BOLT

12

01643-31232

WASHER

13

21K-46-71160

SHEET

14

21K-46-71210

SHEET

15

21K-46-71220

SHEET

16

21K-46-71230

SHEET

17

21K-46-71241

SHEET

18

21K-46-71291

SHEET

|$26

21K-46-71310

COVER

19

PLATE

20

21K-46-71260

SHEET

21

21K-46-71330

SEAL

|$31

21K-46-71320

COVER

22

PLATE

23

21K-46-71280

SHEET

24

21K-46-71340

SEAL

25

01010-81230

BOLT

26

01643-31232

WASHER

27

21K-46-71350

SHEET

|$41

20Y-46-42411

COVER

28

COVER

29

20Y-46-42231

SEAL

30

20Y-46-42460

SHEET

|$46

20Y-46-42422

COVER

31

COVER

32

20Y-46-42251

SEAL

33

20Y-46-42460

SHEET

34

20Y-46-42470

SEAL

35

20Y-46-42480

SEAL

|$53

20Y-46-42431

COVER

36

COVER

37

20Y-46-42241

SEAL

38

20Y-46-42460

SHEET

39

20Y-46-42490

SEAL

|$59

20Y-46-42440

COVER

40

COVER

40

COVER

41

20Y-46-42260

SHEET

42

20Y-46-42210

SEAL

43

20Y-46-42310

SHEET

44

20Y-46-42320

SHEET

45

20Y-46-42330

SHEET

46

20Y-46-42340

SHEET

47

20Y-46-42350

SHEET

48

20Y-46-42360

SHEET

49

20Y-46-42370

SHEET

50

01010-81035

BOLT

51

01643-31032

WASHER

52

01010-81225

BOLT

53

01643-31232

WASHER

54

21K-46-71180

GROMMET

55

206-46-71180

GROMMET

56

20Y-43-11281

GROMMET

57

20X-06-31130

GROMMET
