Запчасти Komatsu PC160LC-7 ОСНОВН. КЛАПАН (7-КЛАПАН) (/8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$4

723-57-16103

CONTROL VALVE

|$5

723-57-16102

CONTROL VALVE

|$6

723-57-16101

CONTROL VALVE

|$7

723-57-16100

CONTROL VALVE

|$$5

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-28A0.

|$9

723-20-94100

VALVE ASS'Y

1

BLOCK

2

SPOOL

3

723-20-94150

SPRING

4

723-20-94130

PLUG

5

07002-11623

O-RING

6

723-20-94140

FLANGE

7

07000-12011

O-RING

8

07000-11006

O-RING

9

07000-11007

O-RING

10

01252-60616

BOLT

11

BALL

12

PLUG

13

07000-11003

O-RING

14

07002-10823

O-RING

15

PLUG
