Запчасти Komatsu PC160LC-7 ОСНОВН. КЛАПАН (-КЛАПАН) (9/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$4

723-56-16103

CONTROL VALVE

|$5

723-56-16102

CONTROL VALVE

|$6

723-56-16101

CONTROL VALVE

|$7

723-56-16100

CONTROL VALVE

|$$5

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 TO Y1660-25A0.

|$9

723-50-53200

VALVE ASS'Y

1

BLOCK

2

VALVE

3

702-21-35130

SEAL

4

723-50-53330

SPRING

5

SLEEVE

6

07000-12010

O-RING

7

07001-02010

RING

8

07000-12012

O-RING

9

07001-02012

RING,BACK-UP

10

SEAT

11

07000-12016

O-RING

12

PISTON

13

723-50-53350

SPRING

14

723-50-53270

PLATE

15

723-50-53260

RETAINER

16

07000-12015

O-RING

17

07000-13030

O-RING

18

01252-60630

BOLT

19

PLUG

20

700-13-31161

O-RING

21

07000-11007

O-RING
