Артикул
Название
Примечание
Количество
|$4
723-56-16103
CONTROL VALVE
|$5
723-56-16102
CONTROL VALVE
|$6
723-56-16101
CONTROL VALVE
|$7
723-56-16100
CONTROL VALVE
|$$5
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 TO Y1660-25A0.
|$9
BODY GROUP
|$10
BODY GROUP
1
SPOOL
1
SPOOL
2
SPOOL
3
PLUG
3
PLUG
4
O-RING
4
O-RING
5
723-26-15121
RETAINER
6
723-26-16740
RETAINER
7
723-26-14520
SPRING
8
723-26-14530
SPRING
9
723-26-14540
SPRING
10
723-26-16730
PISTON
11
723-26-16710
CASE
12
723-26-16720
CASE
13
575-41-17420
O-RING
14
07000-11005
O-RING
15
01252-60630
BOLT
16
01252-60645
BOLT
Выбрано товаров: 26
