Запчасти Komatsu PC160LC-7 ОСНОВН. КЛАПАН (-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$4

723-56-16103

CONTROL VALVE

|$5

723-56-16102

CONTROL VALVE

|$6

723-56-16101

CONTROL VALVE

|$7

723-56-16100

CONTROL VALVE

|$$5

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 TO Y1660-25A0.

|$9

BODY GROUP

|$10

BODY GROUP

|$11

BODY GROUP

1

VALVE

2

723-56-31620

SPRING

3

723-56-31630

PLUG

4

07002-11623

O-RING

5

VALVE

5

VALVE

6

709-70-91420

SPRING

7

723-56-31660

RETAINER

8

723-56-31670

SEAT

9

723-56-31640

PLUG

10

07002-11623

O-RING

11

07000-11008

O-RING
