Артикул
Название
Примечание
Количество
|$4
723-56-16103
CONTROL VALVE
|$5
723-56-16102
CONTROL VALVE
|$6
723-56-16101
CONTROL VALVE
|$7
723-56-16100
CONTROL VALVE
|$$5
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1660-01A0 TO Y1660-25A0.
|$9
BODY GROUP
|$10
BODY GROUP
|$11
BODY GROUP
1
BLOCK,VALVE
2
BLOCK,VALVE
3
BLOCK,VALVE
4
144-14-54610
O-RING
5
723-56-31720
O-RING
6
723-56-31730
O-RING
7
702-75-11520
O-RING
8
07000-12012
O-RING
9
07000-11008
O-RING
10
SPOOL
10
SPOOL
11
SPOOL
12
SPOOL
13
VALVE
14
SPRING
15
PLUG
16
PLUG
17
O-RING
18
SEAL
19
723-56-31211
RETAINER
20
723-56-31221
RETAINER
21
723-36-14110
SPRING
22
723-36-14120
SPRING
23
723-36-14130
SPRING
24
723-56-31421
SPRING
Выбрано товаров: 33
