Артикул
Название
Примечание
Количество
|$1
708-8F-00230
MOTOR ASS'Y
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1641-01A0 TO Y1641-03A0.
1
708-8F-32121
SHAFT
2
708-8F-12151
BEARING
3
708-7L-12140
BEARING
4
708-7L-05010
SPACER KIT
4
SPACER, 1.5MM
4
SPACER, 1.6MM
4
SPACER, 1.7MM
4
SPACER, 1.8MM
4
SPACER, 1.9MM
4
SPACER, 2.0MM
5
706-7G-11291
SEAL,OIL
6
708-8F-12230
SPACER, 3.2MM
7
04065-07225
RING
8
BLOCK,CYLINDER
9
PLATE,VALVE
10
PIN
11
708-8F-33360
PIN
12
708-7L-13140
SEAT
13
708-8F-33160
SPRING
14
04065-04818
RING,SNAP
15
708-8F-33350
GUIDE,RETAINER
16
708-2L-33350
RETAINER,SHOE
17
708-8F-33310
PISTON SUB ASS'Y
18
708-8F-33490
CAM,ROCKER
19
708-8F-33710
BALL,RETAINER
20
708-8F-34141
PISTON
21
708-8F-34240
SPRING
22
708-8F-34250
SPRING
23
708-8F-35110
PLATE
24
708-8F-35130
PLATE
25
708-8F-35120
DISC
26
708-8F-35140
PISTON,BRAKE
27
708-8F-35160
O-RING
28
708-8F-35170
RING,BACK-UP
29
708-8F-35180
O-RING
30
708-8F-35190
RING,BACK-UP
31
708-8F-35150
SPRING
32
04025-00324
PIN,SPRING
Выбрано товаров: 40
