Запчасти Komatsu PC160LC-7 ЦИЛИНДР КОВША (СИСТЕМА СМАЗКИ 100 ЧАС.)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS180

CYLINDER GROUP,(FINAL COATING)

|$$2

====================

|$3

707-01-0H390

CYLINDER ASS'Y

1

707-13-10530

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

721-58-70160

ROD,PISTON

5

707-76-70370

BUSHING

6

20Y-70-23220

SEAL,DUST (KIT)

7

707-27-10971

HEAD,CYLINDER

8

07179-12084

RING,SNAP

9

144-63-95170

SEAL,DUST (KIT)

10

707-52-90470

BUSHING

11

707-51-70030

PACKING,ROD (KIT)

12

07000-15095

O-RING (KIT)

13

707-35-91060

RING,BACK-UP (KIT)

14

707-51-70640

RING,BUFFER (KIT)

15

01010-81465

BOLT

16

705-17-04980

WASHER

17

707-36-10750

PISTON

18

707-44-10280

RING,PISTON (KIT)

19

707-39-10550

RING,WEAR (KIT)

20

707-44-10911

RING

21

707-35-90730

RING (KIT)

22

707-34-60030

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00000

FITTING,GREASE

26

707-86-47390

TUBE

27

707-87-24100

ELBOW

28

01010-80850

BOLT

29

01643-50823

WASHER

30

01010-81080

BOLT

31

01643-51032

WASHER

32

07000-13025

O-RING (KIT)

33

07000-13030

O-RING (KIT)

34

707-88-22940

BRACKET

35

707-88-21650

BAND

36

07372-21035

BOLT

37

01643-51032

WASHER

38

07283-32236

CLIP

39

01597-01009

NUT

40

01643-31032

WASHER

41

02896-61015

O-RING (KIT)

|$$45

====================

|$46

707-99-37290

SERVICE KIT
