Запчасти Komatsu PC160LC-7 ЦИЛИНДР СТРЕЛЫ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX770

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XX780

CYLINDER GROUP,R.H. (FINAL COATING)

|$$3

====================

|$5

707-01-0E490

CYLINDER ASS'Y

1

707-13-11160

CYLINDER

2

21K-70-71320

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-75650

ROD,PISTON

6

21K-70-71320

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

707-27-11720

HEAD,CYLINDER

9

07179-13089

RING,SNAP

10

144-63-94170

SEAL,DUST (KIT)

11

707-52-90500

BUSHING

12

707-51-75030

PACKING,ROD (KIT)

13

07000-15100

O-RING (KIT)

14

707-35-91130

RING,BACK-UP (KIT)

15

707-51-75640

RING,BUFFER (KIT)

16

01010-81670

BOLT

17

01643-51645

WASHER

18

721-36-11020

PISTON

19

707-44-11180

RING,PISTON (KIT)

20

707-39-11150

RING,WEAR (KIT)

21

707-44-11911

RING

22

707-71-70810

PLUNGER

23

07000-15070

O-RING (KIT)

24

707-35-90360

RING,BACK-UP (KIT)

25

01310-01216

SCREW

26

707-71-34400

COLLAR

27

707-35-91130

RING,BACK-UP (KIT)

28

07000-15100

O-RING (KIT)

29

707-86-47400

TUBE,L.H.

29

707-86-47410

TUBE,R.H.

30

707-86-66780

TUBE,L.H.

30

707-86-66790

TUBE,R.H.

31

01010-80845

BOLT

32

01643-50823

WASHER

33

01435-01055

BOLT

34

01435-01040

BOLT

35

07000-13025

O-RING (KIT)

36

07000-13030

O-RING (KIT)

37

707-88-22910

BRACKET,L.H.

37

707-88-22920

BRACKET,R.H.

38

707-88-21640

BAND

39

01435-01030

BOLT

40

07283-32236

CLIP

41

07283-32738

CLIP

42

01597-01009

NUT

43

01643-31032

WASHER

44

02896-61015

O-RING (KIT)

45

02896-61018

O-RING (KIT)

|$$53

====================

|$55

707-99-38720

SERVICE KIT
