Запчасти Komatsu PC160LC-7 ОСНОВН. НАСОС (8/9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

708-3M-00020

PUMP ASS'Y

|$3

708-3M-00011

PUMP ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-09A0.

|$5

708-3M-03620

VALVE ASS'Y,LS

|$6

708-2L-06751

VALVE ASS'Y,LS

1

708-2L-35311

SLEEVE

2

708-2L-24680

SEAL

3

708-2L-35550

SPOOL

4

708-2L-28540

PISTON

5

708-2L-35360

SLEEVE

6

708-2G-15420

SEAT

6

708-2L-35331

SEAT

7

708-2L-35410

SPRING

8

708-2L-35341

SEAT

9

708-2L-35351

PLUG

10

07000-B1009

O-RING

11

07001-01009

RING,BACK-UP

12

01583-11408

NUT

13

07002-62434

O-RING
