Запчасти Komatsu PC160LC-7-E0 ЦИЛИНДР СТРЕЛЫ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XN100

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XN110

CYLINDER GROUP,R.H. (FINAL COATING)

|1

707-01-0L100

CYLINDER ASS'Y

1

707-13-11790

CYLINDER

2

707-58-75650

ROD,PISTON

3

21K-70-71320

BUSHING

4

07145-00070

SEAL,DUST (KIT)

5

07020-00000

FITTING,GREASE

6

21K-70-71320

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

707-71-32580

COLLAR

9

07000-15100

O-RING (KIT)

10

707-71-70810

PLUNGER

11

707-35-91130

RING,BACK-UP (KIT)

12

707-27-11650

HEAD,CYLINDER

13

144-63-94170

SEAL,DUST (KIT)

14

07179-13089

RING,SNAP

15

707-51-75030

PACKING,ROD (KIT)

16

707-51-75650

RING,BUFFER (KIT)

17

07000-15100

O-RING (KIT)

18

707-35-91130

RING,BACK-UP (KIT)

19

707-52-90500

BUSHING

20

707-75-75110

RING,SNAP

21

01010-81670

BOLT

22

01643-51645

WASHER

23

721-36-11020

PISTON

24

707-44-11150

RING,PISTON (KIT)

25

707-39-11150

RING,WEAR (KIT)

26

707-44-11911

RING

27

01310-01216

SCREW

28

07000-15070

O-RING (KIT)

29

707-35-90360

RING,BACK-UP (KIT)

30

707-86-68270

TUBE,L.H.

|30

707-86-68280

TUBE,R.H.

31

02896-61015

O-RING (KIT)

32

707-86-66780

TUBE,L.H.

|32

707-86-66790

TUBE,R.H.

33

02896-61018

O-RING (KIT)

34

01010-80840

BOLT

35

01643-50823

WASHER

36

07372-21060

BOLT

37

01643-51032

WASHER

38

07372-21045

BOLT

39

01643-51032

WASHER

40

07000-13025

O-RING (KIT)

41

07000-13030

O-RING (KIT)

42

707-88-22910

BRACKET,L.H.

|42

707-88-22920

BRACKET,R.H.

43

707-88-21640

BAND

44

07372-21035

BOLT

45

01643-51032

WASHER

46

07283-32236

CLIP

47

07283-32738

CLIP

48

01597-01009

NUT

49

01643-31032

WASHER

50

01010-80845

BOLT

51

01643-50823

WASHER

52

02789-00522

PLUG

53

02789-00628

PLUG

|K

707-99-38760

SERVICE KIT
