Запчасти Komatsu PC1600SP-1 ЦИЛИНДР КОВША(№-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
G1
21T-63-X2050
CYLINDER GROUP,L.H.
G1
21T-63-X2060
CYLINDER GROUP,R.H.
|$3
21T-63-02050
CYLINDER ASS'Y
1
21T-63-72142
CYLINDER
2
21T-63-72121
ROD,PISTON
3
707-46-14010
BUSHING
4
21T-72-15850
BUSHING
5
21T-72-15860
BUSHING
6
21T-72-15870
SEAL (KIT)
7
707-75-14012
RING,SNAP
8
198-63-93170
SEAL,DUST (KIT)
9
707-28-20150
HEAD,CYLINDER
10
707-51-14130
PACKING,ROD (KIT)
11
07001-05200
RING,BACK-UP (KIT)
12
07000-15200
O-RING (KIT)
13
707-51-14630
RING,BUFFER (KIT)
14
707-52-91150
BUSHING
14
707-52-11410
BUSHING
15
01011-83025
BOLT
16
01643-33080
WASHER
17
01011-83005
BOLT
18
01643-33080
WASHER
19
707-71-73330
CAPILLARY
20
07042-20108
PLUG
21
07000-11009
O-RING (KIT)
22
07001-01009
RING,BACK-UP (KIT)
23
07002-11823
O-RING (KIT)
24
707-36-20931
PISTON
25
707-44-20180
RING,PISTON (KIT)
25
707-44-20080
RING,PISTON (KIT)
26
07155-02045
RING,WEAR (KIT)
27
707-39-20911
RING,WEAR (KIT)
28
19M-63-52271
NUT
29
07000-12095
O-RING (KIT)
30
07001-02095
RING,BACK-UP (KIT)
31
707-71-51520
PLUNGER
32
707-71-31531
COLLAR
33
707-71-31540
COLLAR
34
707-71-11510
RING
34A
07043-00108
PLUG
35
21T-63-72370
TUBE,L.H.
35
21T-63-72470
TUBE,R.H.
36
21T-63-72380
TUBE,L.H.
36
21T-63-72480
TUBE,R.H.
37
707-88-96650
BRACKET
38
707-88-96660
BRACKET
39
707-88-96640
BAND
40
01010-51240
BOLT
41
01643-31232
WASHER
42
01010-51450
BOLT
43
01643-31445
WASHER
44
07000-13048
O-RING (KIT)
45
176-61-41330
CLAMP
46
01010-51250
BOLT
47
707-88-10930
BRACKET
48
01010-51230
BOLT
49
01010-51235
BOLT
50
07283-24354
CLIP
51
01599-01011
NUT
52
01643-31032
WASHER
53
707-88-10940
BRACKET
54
209-63-52170
PLATE
55
01010-51020
BOLT
56
01602-21030
WASHER
57
07000-13048
O-RING,(FOR SHIPPING)
58
07378-11410
HEAD,(FOR SHIPPING)
59
07371-51470
FLANGE,(FOR SHIPPING)
60
01010-51455
BOLT,(FOR SHIPPING)
61
01643-31445
WASHER,(FOR SHIPPING)
|$71
707-99-77210
SERVICE KIT
Выбрано товаров: 70
