Запчасти Komatsu PC1600SP-1 БЛОК КОНДИЦИОНЕРА (/)(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

G-1

21T-979-X100

AIR CONDITIONER G.,(LOW CAB)

|$3

195-911-7201

AIR CONDITIONER UNIT

|$4

195-911-7200

AIR CONDITIONER UNIT

|$6

195-911-7211

UNIT ASS'Y

|$7

195-911-7210

UNIT ASS'Y

1

195-Z11-5540

MOTOR ASS'Y

2

195-Z11-5560

PACKING

3

145-Z79-6660

BOLT

4

145-Z79-6670

INSERT

5

145-Z79-6680

BUSHING

6

195-Z11-5570

FAN,BLOWER

7

198-911-5540

WASHER

8

198-911-5530

NUT

9

195-Z11-5580

PIPE

10

195-911-7330

WIRING HARNESS

11

195-911-7340

SWITCH,PRESSURE

12

ND949142-0040

O-RING

13

195-Z11-5590

RESISTOR,BLOWER

14

01220-40416

SCREW

15

195-Z11-5840

RELAY ASS'Y

16

195-Z11-6150

CLAMP

17

01010-80616

BOLT

18

195-Z11-5892

COVER

19

195-Z11-5880

CLAMP

20

195-Z11-5810

GROMMET

21

195-Z11-5940

SCREW

22

195-Z11-7160

CLAMP

23

01010-80816

BOLT

24

ND113104-0160

PLATE, NAME,(LIMITED SUPPLY)

25

195-Z11-7180

ACTUATOR ASS'Y

26

195-Z11-6210

LINK

26A

ND146690-1990

CLAMP

27

195-Z11-6260

SHAFT

27A

195-Z11-6270

SPRING

28

195-Z11-6280

BUSHING

29

01370-00412

SCREW

30

195-Z11-7190

ACTUATOR ASS'Y

31

195-Z11-6220

LINK

31A

ND146690-1990

CLAMP

32

01010-80616

BOLT

33

195-Z11-6191

DAMPER

33A

195-Z11-6640

BUSHING

34

195-Z11-6270

SPRING

35

ND146669-4940

PACKING

36

ND146669-1170

PACKING

37

195-Z11-6182

AMP ASS'Y

37

195-Z11-6181

AMP ASS'Y

38

195-Z11-5862

HOLDER

39

195-Z11-5870

FILTER

40

195-Z11-5920

COVER

41

01010-80816

BOLT

42

195-Z11-6270

SPRING

43

205-979-6460

RELAY ASS'Y
