Запчасти Komatsu PC1600SP-1 ОСНОВН. НАСОС (/8) (NO. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC1600SP-1 - ОСНОВН. НАСОС (/8) (NO. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

Артикул

Название

Примечание

Количество

|1

708-25-03011

PUMP ASS'Y

|1

708-25-03010

PUMP ASS'Y

|1

708-25-04180

PUMP SUB ASS'Y

|1

708-25-51201

PUMP SUB ASS'Y

|1

708-25-00310

CASE ASS'Y,FRONT

1

CASE,FRONT

2

PLUG

3

07044-12412

PLUG

4

07002-02434

O-RING

|5

708-25-00660

END CAP ASS'Y,FRONT

|5

708-25-00340

END CAP ASS'Y,FRONT

5

CAP,FRONT

|5

CAP,FRONT

6

PLUG

7

708-2E-12260

BEARING

|7

708-25-12740

BEARING

8

07000-02135

O-RING

9

6130-21-1910

PIN,DOWEL

10

07000-12015

O-RING

11

07000-11009

O-RING

12

07000-03032

O-RING

13

708-25-12530

BOLT

14

04530-01018

BOLT,EYE

15

708-25-52710

SHAFT,FRONT

16

708-2L-22150

BEARING

17

708-25-05010

WASHER KIT

|17

WASHER¤ 2.0MM

|17

WASHER¤ 2.1MM

|17

WASHER¤ 2.2MM

18

708-25-12790

RING,SNAP

19

708-25-05140

WASHER KIT

|19

WASHER¤ 2.25MM

|19

WASHER¤ 2.55MM

|19

WASHER¤ 2.85MM

|19

WASHER¤ 3.15MM

|19

WASHER¤ 3.45MM,3.45MM

|19

WASHER¤ 3.75MM,3.75MM

20

06000-51106

BEARING

21

708-25-52830

RING

22

708-25-52840

RETAINER

23

708-25-05021

SHIM KIT

|23

SHIM¤ 0.5MM,0.50MM

|23

SHIM¤ 0.2MM,0.20MM

|23

SHIM¤ 0.15MM,0.15MM

|23

SHIM¤ 0.1MM,0.10MM

24

708-25-12950

PLATE

25

706-74-40320

BOLT

26

01643-31032

WASHER

27

708-25-52860

SEAL,OIL

28

708-25-12812

HOUSING

|28

708-25-12811

HOUSING

29

07000-02080

O-RING

30

708-25-05130

SHIM KIT

|30

SHIM¤ 0.2MM

|30

SHIM¤ 0.1MM

31

01010-80820

BOLT

|31

01010-30820

BOLT

32

01643-30823

WASHER

Выбрано товаров: 58
