Запчасти Komatsu PC1600-1 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-77-01041

MOTOR ASS'Y

|1

706-77-01040

MOTOR ASS'Y

|1

706-77-03111

MOTOR SUB ASS'Y

|1

706-77-03110

MOTOR ASS'Y

1

706-87-40160

BOLT

2

07000-05250

O-RING

3

706-77-42012

CASE,BRAKE

4

706-77-42071

BUSHING

5

706-77-43850

PLATE,VALVE

6

04020-01024

PIN

7

706-77-42081

SHAFT,CENTER

|8

706-77-00030

CYLINDER BLOCK ASS'Y

8

BLOCK

|8

BLOCK

9

RING,CENTER

|9

RING,CENTER

10

706-77-42110

SPRING

11

706-77-42160

PISTON SUB ASS'Y

12

706-77-42260

RETAINER

13

706-75-41271

SCREW

14

706-77-42861

SHAFT,DRIVE

15

706-77-42881

BEARING

|15

706-77-42880

BEARING

16

706-77-42890

BEARING

17

706-77-42041

SEAT

18

706-77-42051

SPRING

19

706-77-05010

SPACER KIT

|19

SPACER¤ 2.3MM

|19

SPACER¤ 2.5MM

|19

SPACER¤ 2.7MM

20

04064-06525

RING

21

706-77-42060

COVER

22

07000-02115

O-RING

23

706-77-42950

SEAL,OIL

24

04071-00130

RING,SNAP

25

706-73-71450

PLUG

26

07002-11423

O-RING

27

07000-12010

O-RING

28

706-77-72121

HOUSING

29

706-77-72130

VALVE

30

706-77-72140

SPRING

31

706-77-72150

PLUG

32

07002-14234

O-RING

33

706-77-72170

PLUG

34

07002-12434

O-RING

35

07040-13016

PLUG

36

07002-03034

O-RING

37

706-77-91331

PLATE

38

706-77-91341

PLATE

39

706-77-91350

DISC

40

706-77-91480

PISTON,BRAKE

41

07000-15200

O-RING

42

07001-05200

RING

43

07000-15220

O-RING

44

07001-05220

RING

45

706-75-42830

PIN,DOWEL

46

706-77-91410

SPRING
